| GP9 project, getting ready to machine all the parts for the brake rigging on the trucks |
©
-20 - 2025 Tom Downing |
|
|
| |
Don't
Forget! Leave a comment about this photo
below.
|
|
|
 Send
this image as an E-Postcard to a friend. Click
HERE  |
|
|
| Picture
Title: |
GP9 project, getting ready to machine all the parts for the brake rigging on the trucks |
| Location: |
|
| Photographer: |
Tom Downing |
| Submission
Date: |
7/11/2025 6:44:19 PM |
| Comments: |
This was a pretty tricky part of the project. The trucks with the kit didn’t come with any brake rigging. I was looking around in the members container and there’s an area where there’s just a bunch of leftover parts. I found a box with marking on the side of it that said EMD breaks as you can see there’s not much to it a lot of drilling and tapping and kind of figuring everything out because there were no instructions or blueprints so I just looked at pictures kind of went from there. The brakes are functioning, but are not powered. I didn’t have to put the brakes on the trucks, but to me look better with the brake rigging, even though it was a lot of work. |
| Gallery Category: |
Diesel |
| Technical
Information: |
| Shooting Location: |
|
| Owner: |
|
| Locomotive Name or Road: |
|
| Locomotive or Car Type: |
|
| Whyte Classification |
Numeric: Name: Layout: Class: |
| Track Gauge: |
7.5 |
